Somfy Orea RTS 40/17 Repair (Does Not Retract)

Repairing Somfy Orea RTS 40/17: powerful radio motor for large cassette awnings

With 40 Nm of torque, the Somfy Orea 50 RTS 40/17 is one of the most powerful motors in the Orea 50 series and can even move large cassette awnings. If it loses power, it's rarely a total loss. In most cases, a fixed-price repair is sufficient, instead of replacing the entire motor.

Note regarding usability: As long as the motor is defective, your awning will remain in its last extended position. An extended awning cannot be retracted in windy or rainy conditions and is therefore particularly vulnerable. We recommend having any detected defect repaired promptly.

Typical defects of the Orea RTS 40/17

• The awning extends, but when retracting it stops under the weight of the fabric.
• The motor hums audibly and only starts turning when you assist it manually.
• When engaging the cassette, there is insufficient power to fully close it, but the drive responds normally to the radio transmitter.

This is explained by the design of the cassette awning: When extending, the spring-loaded articulated arms provide powerful assistance, so the motor hardly has to work. When retracting, it pulls the large fabric back against these springs alone, requiring the full power of the motor. If this power diminishes, it becomes apparent first during retraction, especially with this powerful drive. The cause is almost always a single defective component inside the drive, which we replace.

What happens during the repair

We open the drive unit, replace the defective component, and then test the Somfy Orea RTS 40/17 under load. Only when it retracts the awning quickly and with full power do we release it.

When another service is suitable

If the awning doesn't stay in its end position or the fabric retracts slightly on its own, the brake or gearbox is faulty. In that case, we'll replace the motor tube; we have a replacement part available for the Orea RTS 40/17. However, if the drive doesn't respond to the remote control at all or only reacts with a brief twitch, the radio electronics are defective, and we'll replace the motor head and control unit.

Repair process

You commission the repair via the shopping cart and receive shipping instructions by email. You send the motor via Hermes to our Hermes ParcelShop, where we will personally accept it. The repair is carried out on the day it arrives, and you will receive the invoice by email on the same day. After payment is received, the drive unit is shipped back to you insured; for instant bank transfers, this occurs on the same day.

You will receive this

• Fixed price repair for €49, plus shipping.
• Repair on the day of receipt
• 24-month warranty on the replaced components
• Invoice after successful repair, return shipping after payment is received.

This service applies to the Somfy Orea 50 RTS 40/17 with reference 5005479.

Frequently asked questions about the Somfy Orea RTS 40/17

How much does it cost to repair the Somfy Orea RTS 40/17?

The repair costs a fixed price of €49. You will receive the invoice after successful repair, return shipping will take place after payment is received, and you will receive a 24-month warranty on the replaced parts.

How does the repair process work?

You order the repair via the shopping cart and receive shipping instructions by email. You send the motor via Hermes; the repair is carried out on the day of receipt, and the drive is returned insured after payment has been received.

Do I need to remove the motor and send it in?

Yes, the repair is done by sending the unit in. You can find the exact model name on the motor's nameplate.

Where can I find the instruction manual for Somfy Orea RTS 40/17?

You can find the relevant instruction manual on this page under the "Download" tab. You don't need it for the repair; simply send us the removed device.
